Function description
CF-25, CF-35, CF-40, CF-50, CF-60
Operating panel (Fig. 4, page 4)
CF-25
Connection sockets (Fig. 5, page 4):
CF-35, CF-40, CF-50, CF-60
Connection sockets (Fig. 6, page 4):
Item Description Explanation
1 ON
OFF
Switches the cooler on or off when the
button is pressed for between one and
two seconds
2 POWER Status indication
LED lights up
green:
Compressor is on
LED lights up
orange:
Compressor is off
3 ERROR LED flashes red: Device is switched
on but not ready for
operation
4 SET Selects the input mode
- Temperature setting
- Celsius or Fahrenheit display
- Set battery monitor
5 – Display, shows the information
6 UP + Press once to increase the value
7 DOWN – Press once to decrease the value
Item Description
1 Connection socket DC voltage supply
Item Description
1 Connection socket AC voltage supply
2 Fuse holder
3 Connection socket DC voltage supply
_CF-18_60.book Seite 34 Donnerstag, 26. Juli 2007 3:18 15
13
