5.2 Fitting cavity
WARNING
WARNING
The appliance must fitted at an appropriate and safe distance from flammable materials.
WARNING
WARNING – For CU3… and FO311 models
The cavity that the appliance is built into must be completely sealed off. It is important that
the inside panels of the cavity are completely sealed and do not communicate with adjoining
cavities or the outside. The openings in the cavity that allow access to the gas and electric
connections should be sealed with rubber or foam.
The gas connection (1/4 BSPT female) is located at the rear for models CU..., FO... and for model VN555,
whereas it is on the bottom for models PI... and MO...
The electric connection is located at the rear for models CU..., FO... and for model VN555, whereas it
is on the bottom for models PI... and MO... (consult chapter 4.4 Electric connection to see whether the
appliance needs this connection).
Minimum allowable distances from walls (FIG. 4 - PG. 23)
100 mm From the external edge of the burner head nearest to the back wall (for CU4... and
PI80... models with glas lid).
200 mm From the external edge of the burner head nearest to a side and / or back wall.
500 mm Between the top part of the burners and cabinets and / or shelves fitted above the
hotplate (for all models except CU401).
550 mm Between the top part of the burners and cabinets and / or shelves fitted above the
hotplate (for CU401 model).
100 mm From the sides of the appliance and vertical walls.
170 mm From the top side to the cabinets and / or shelves fitted above the appliance.
Dimensions of fitting cavity
Cut out a hole in the cabinet as illustrated in FIG. 5 - PG. 24 size will depend on appliance model.
The cabinet must be appropriately constructed and aligned horizontally with the worktop and with the unit.
The cabinet aperture must be perfectly squared and aligned. If there are apertures for cabinet ventilation,
prevent flammable materials from entering these.
5.3 Gas connection
WARNING
WARNING
This appliance shall be installed only by authorised persons and in accordance with the
manufacturer’s installation instructions, local gas fitting regulations, municipal building
codes, electrical wiring regulations, AS/NZS5601.2.2013 - Gas Installations and any other
statutory regulations.
WARNING
WARNING
This appliance is not connected to a flue terminal which discharges the product of
combustion to the outside. Any enclosed space in which the appliance is installed must
therefore be provided with permanent ventilation in accordance with relevant federal and
state regulations in force, and the requirements of gas installations with particular attention
being paid to the matter of room ventilation.
