5. INSTALLATION
EN
15
NOMINAL GAS CONSUMPTION
Model
AUXILIARY
Ø 47 mm
SEMI-RAPID
Ø 62 mm
RAPID
Ø 77 mm Grill Oven
TOTAL
NOMINAL GAS
CONSUMPTION
№
MJ/h
№
MJ/h
№
MJ/h
№
MJ/h
№
MJ/h MJ/h
PI7903 1 3.8 1 5.9 1 7.2 16.9
PI7923 1 3.8 1 5.9 1 7.2 16.9
PI8002 1 3.8 1 5.9 9.7
PI8022 1 3.8 1 5.9 9.7
PI8003 1 3.8 2 5.9 15.6
PI8023 1 3.8 2 5.9 15.6
PI8403 1 3.8 2 5.9 15.6
PI8403GL 1 3.8 2 5.9 15.6
PI8423 1 3.8 2 5.9 15.6
PI8423GL 1 3.8 2 5.9 15.6
PI8443 1 3.8 2 5.9 15.6
PI8463 1 3.8 2 5.9 15.6
PI8621A 1 3.8 3.8
PI8621R 1 7.2 7.2
PI8621S 1 5.9 5.9
VN555 1 5.2 5.2
BURNER INJECTOR ORIFICE (mm) STAMPED №
AUXILIARY (Ø 47mm) 0.57 57
SEMI-RAPID (Ø 62mm) 0.72 72
RAPID (Ø 77mm) 0.80 80
GRILL 0.67 67
OVEN 0.57 57
The connection of the gas pipe to the appliance (1/4 BSPT female) must be made with a rigid metal pipe.
The pipe work and fittings shall be free from defects and of an approved type.
Once installed, the installation must be checked for leaks by means of an approved testing method.
Do not use a solution of soap and water.
WARNING
WARNING
Never use a naked flame to check for gas leaks.
5.4 Electric connection
Low voltage 12 V
This chapter concerns only models marked 12 V on the appliance data plate.
