4. USE
EN
8
4.3 Hotplate
4.3.1 Selecting the burner
WARNING
WARNING
The flame must never extend beyond the edge of the pan. Centre the pan over the burner
ensuring stability on the pan support.
Burner
Pan diameter
Min Max
Auxiliary
Ø 47 mm
6 cm 16 cm
Semi-rapid
Ø 62 mm
16 cm 22 cm
Rapid
Ø 77 mm
16 cm 22 cm
4.3.2 Electronic ignition hotplate (depending on model)
WARNING
WARNING
Make sure there are no pans or any other objects on the burners when igniting.
To ignite the burner, gently push in and turn the control knob to position HIGH FLAME and, keeping the
knob pushed in, at the same time press the electronic ignition pushbutton. Once the burner is lit, keep the
knob pushed in for a few seconds to ensure the flame remains lit.
CAUTION
CAUTION
If the burner does not ignite immediately repeat ignition after having followed each step
below:
• Turn the knob to “Low flame ”
• Proceed with manual ignition
• Check there is sufficient gas in the gas bottle.
If the appliance still does not ignite shut off the gas supply at the main gas tap and contact
your local dealer.
4.3.3 Manual ignition hotplate
Manual ignition when the appliance is not fitted with the electronic ignition feature or in the event of
failure in the electronic ignition.
WARNING
WARNING
Make sure there are no pans or any other objects on the burners when igniting.
To ignite the burner, gently push in and turn the control knob to position HIGH FLAME and, keeping the
knob pushed in, at the same time light the burner with a match or gas lighter. Once the burner is lit, keep
the knob pushed in for a few seconds to ensure the flame remains lit.
CAUTION
CAUTION
If the burner does not ignite immediately, check there is sufficient gas in the gas bottle.
If the appliance still does not ignite, shut off the gas supply at the main gas tap and contact
your local dealer.
