5. INSTALLATION
EN
16
CAUTION
CAUTION
This appliance must be connected to a 12 V source. The circuit must be protected by a
fuse of no more than 3 Ampere.
Ensure that the polarity of the connection is correct!
WARNING
WARNING
Absolutely do not connect the appliance to the mains voltage (230 V~), this would destroy
the components and cause a hazard for the user.
To connect the appliance use a 1.5 mm
2
double red and black wire and wire to the terminal junction box
located at the rear of the appliance with the wording “+12 V – “. The red terminal is the positive pole
and the black terminal is the negative pole.
High voltage 230-240 V~
This chapter refers only to the models listed in the table below.
Model Nominal voltage Nominal power
CU401PE - CU402PE - CU403PE 230-240V~ 800 W
In these models there is an electric plate in the hotplate.
WARNING
WARNING
When connecting direct to the mains supply, it is necessary to install a circuit breaker
which allows for disconnecting and isolating the appliance from the mains in the event of
overvoltage III conforming to installation regulations.
The supply cord must be positioned in such a way that it never reaches a temperature of
75°C above ambient in any point.
The plug must be easy to access after installation.
Always disconnect electrical power before working on or servicing the appliance.
For connecting to the mains power supply use a socket.
If the supply cord (H05RR-F 3x0,75mm
2
) is damaged, it must be replaced by the manufacturer or its
service agent or a similarly qualified person in order to avoid a hazard.
5.5 Fixture
CAUTION
CAUTION
This appliance is to be fixed and secured to the cabinet as described in FIG. 6 – PG. 31.
5.6 Testing (before leaving)
Ignite all burners both individually and concurrently to ensure correct operation of gas valves, burners and
ignition. Turn gas taps to low flame position and observe stability of the flame for each burner individually
and concurrently. Ensure correct operation of the flame failure protection.
Depending on the type of gas used, the appearance of the flame is as follows:
Propane: flame with blue centre and well-defined contour.
Butane: flame with light yellow tips when igniting the burner, gradually intensifying as the burner heats.
