FIGURES AND
TECHNICAL DRAWINGS
EN
25
20 mm 20 mm488 mm
MIN. 494 mm
479 mm
MIN. 21 mm
MIN. 500 mm
651 mm
488 mm
651 mm
TOP VIEW SIDE VIEWFRONT VIEW
20 mm 20 mm
488 mm
MIN. 494 mm
479 mm
MIN. 500 mm
488 mm
281 mm
281 mm
MIN. 21 mm
TOP VIEW
SIDE VIEWFRONT VIEW
20 mm 20 mm488 mm
MIN. 494 mm
479 mm
MIN. 500 mm
488 mm
132 mm 132 mm
MIN. 21 mm
TO P VIEW
SIDE VIEWFRONT VIEW
VENT (INCLUDED)
CU401
CU401PE
CU402
CU402PE
514 mm
592 mm
535 mm
514 mm
292 mm
535 mm
CU311M
CU333M
CU335M
525 mm
505 mm
574 mm
524 mm 500 mm
SIDE VIEWFRONT VIEW
505 mm 505 mm
MIN. 460 mm
500 mm
MIN. 45 mm
SIDE VIEWFRONT VIEW
393 mm 393 mm
415 mm
