Dometic Go Power! 30 AMP RVC MPPT User Manual

gpelectric.com | [page 5]
2.1 OVERVIEW
The 30A RV-C MPPT solar controller is an advanced dual bank controller with RV-C communication for smart RV systems.
As an MPPT Solar controller it continuously monitors the solar panel’s generating power and tracks the maximum power
point, enabling the system to charge the battery with maximum power all the time. It is designed to be used in off-grid
solar photovoltaic systems to coordinate operation of the solar panel, battery, functioning as the core control unit in off-grid
photovoltaic systems.
With comprehensive electronic fault self-detecting functions and powerful electronic protection functions built inside the
controller, component damage caused by installation errors or system failures can be avoided.
This product features an optional LCD remote which displays the operating status and allows the control of congurable
parameters. Users can conveniently check parameters using the buttons and modify control parameters to cater to different
system requirements. The optional remote also includes Bluetooth communication that allows a smart phone to be conveniently
used to perform all the same tasks that the LCD remote can.
2.2 FEATURES
• Advanced multi-peak tracking technology. When the solar panel is shadowed or part of the panel fails resulting in multiple
peaks on the I-V curve, the controller is still able to accurately track the maximum power point
• Built-in maximum power point tracking (MPPT) algorithm signicantly increases energy utilization efciency of the
photovoltaic system, (up to 30% higher than traditional PWM charging)
• MPPT tracking efciency of up to 99.9%
• Power conversion efciency of up to 98%
• Lithium battery reset capability allows a BMS protected over discharged battery to be automatically recovered without
having to disconnect the battery
• Presets for multiple battery chemistries, including LiFePO4, Flooded, Gel and AGM
• Supports user customized charge parameters
• Current-limited charging mode. When the power of solar panel is too large and the charging current is higher than the rated
value, the controller automatically reduces the charging power so that the solar panel can operate at the rated charging
current.
• Features LED fault indicators, which can display abnormal information, helps users to quickly identify system faults.
• Historical data storage function is available
• Minimal derating up to the maximum operating temperature
• Dual-battery management
• Temperature compensation and automatic adjustment of charge parameters help to improve battery life.
•
2. INTRODUCTION

Dometic Go Power! 30 AMP RVC MPPT Specifications

General

Battery Voltage Range	8V – 32V
Max Charge Current	30A
Max Panel Input Voltage	100Voc
Max PV Power Input	600W@12V / 1200W@24V
Conversion Efficiency	≤98%
MPPT Tracking Efficiency	>99%
No-Load Loss	<10mA
Grounding	Negative
Max Wire Gauge	8 AWG
Operating Temperature	-35 to 45°C
Storage Temperature	-35 to 75°C
Humidity	95% N.C.
Water Ingress Protection	IP32
Altitude	< 3000m
Battery Type	Lead Acid (AGM, GEL, Flooded), LiFePO4
Protection	Solar/battery reverse polarity Solar/battery over voltage Solar/battery short circuit Over temperature

Weight and Dimensions

Dimensions (H x W x D)	3.15” x 7.78” x 5.5”
Weight	3.14lbs (1.42kg)
