CLIMATE CONTROL HEATER
To check the switch, disconnect the wires and do a continuity check. In the OFF position, there should
be no continuity. In the ON position, there should be a continuity reading.
To check the heater itself, do an ohms resistance reading on the heater wire by using a properly
calibrated ohm meter. The proper ohms reading is 24 ohms
f
10%. The approximate amp draw is less
than
.5
(1/2)
amp.
LP GAS REQUIREMENTS
The LP gas pressure to the refrigerator should be 11 inches water column with half of all BTU’s of the
RV turned on. With all other appliances off, the pressure to the refrigerator should not exceed 12
inches water column. To check the gas pressure when the refrigerator is operating, there is a pressure
test port on the solenoid.
. .
RM2612
&
RM2812
Power
Module
Cover
liizA_
- -
(12Volt
w
Tel
rminal Block
Manual Gas
Shutoff Valve
Flexible Cord
Inlet
Fitting
RM2652
&
RM2852
Burner
Jet
12
