Dometic SC330 User Manual

EN
No. Description
5 Connection to positive pole of the starting battery
6 Connection to positive pole of the house battery
7 Connection to positive pole of solar panel 1
8 Connection to positive pole of solar panel 2
9 Connection to negative pole of the house battery
10 Connection to negative pole of solar panels
11 Connection to TD283 touch display (accessories) or CI-BUS
12 Connection to TD283 touch display (accessories) or CI-BUS
LED indicators
Table 2: LED indicators
LED Status Description
On Batteries fully charged (100 %)Green
Flashing Charging process
Orange Flashing Charging process, voltage < 12 V
Red Flashing Error (see chapter Troubleshooting on page21)
Battery charging function
A main charging cycle of the house battery is initiated after the house battery voltage has fallen below the reset
voltage.
A main charging cycle of the starting battery is initiated in the following events:
• After falling below the low reset voltage of the starting battery (charging phase of the house battery is not con-
sidered)
• After falling below the reset voltage of the starting battery when the house battery is in trickle charging phase
(Float)
10
