EN
No. Description
3 Temperature sensor
4 WAGO connector
5 Solar panel(s)
House battery
Starting battery (optional)
Table 6: Color coding
Code Colour
rd red
bk black
Connection variant C (SC480 only)
To connect the solar charge controller proceed as shown in Fig. on page16.
16
