The oil level must be between the minimum and maximum marks.
6 -Close the door (A) when the operation has been completed.
CHANGING ENGINE OIL
Proceed as indicated.
1 -Turn the unit off.
2 -Leave the unit to cool down
sufficiently, to avoid the risk
of burning.
3 -Open the door (A).
4 -Provide a container of suffi-
cient capacity.For the amounts
of oil, see "Technical data".
5 -Extract the dipstick (B).
6 -Loosen clamp (C), remove
hose (D) and let the oil flow to
the container.
Use protective gloves to avoid the risk of scorching/burning.
7 -Insert hose (D) onto the extremity of the hose-end fitting and fasten it with clamp (C).
8 -Pour in the new oil until reaching the correct level on the dipstick (B) (See "Do not mix oils
with different characteristics or from different manufacturers.").
