9.3 SPARE PARTS – LEGEND
NR. DESCRIPTION NR. DESCRIPTION
1 GRID PROTECTION 33 GEARS SHAFT
2 BOWL 34 SPACERS
3 UPPER RIGHT ARM 35 FLANGE FOR ARMS SCRAPERS
4 SHAFT FOR BOWL ROTATION 36 BEARINGS
5 FLANGE 37 BOWL BELT
6 BEARING 38 FLANGE
7 TAPERED BEARING 39 SEALING RINGS
8 SPACER 40 SHAFT FOR ARMS PIVOT
9 BEARING 41 BEARING FOR PINION SHAFT
10 BOWL REDUCTION GEAR 42 PINION SHAFT
11 REDUCTION SHAFT 43 SEALING RINGS
12 ROTATING WHEEL 44 TOOTHED WHEELS
13 ADJUSTABEL FOOT 45 SPACER
14 BACK WHEEL 46 BRONZE BUSHING
15 BOXES WITH ELECTRIC PLANT 47 BEARING
16 MOTOR 48 BACK FLANGE
17 SMALL FRONT COVER 49 SPACER
18 COVER FOR GEARINGS BOX 50 IRON RING
19 LARGE FRONT COVER 51 PINION FOR ARM ADJUSTMENT
20 MOTOR PULLEY 52 BEARINGS
21 DRIVING BELT 53 BUSHES
22 GUIDANCE PULLEY 54 LOCKING FLANGE
23 BACK GUARD 55 SPACER
24 ARMS CAPS 56 SUPPORTS FOR RIGHT ARM
25 ARMS RINGS 57 RIGHT DIVING ARM
26 BEARINGS 58 “OR” RING
27 SPACER 59 “IR” RING
28 SUPPORTS FOR LEFT ARM 60 PIVOT FOR MOTOR CARRYING SHAFT
29 UPPER LEFT ARM 61 MOTOR CARRYING SHAFT
30 ARMS CONNECTING RODS 62 UCF BEARING
31 LEFT DIVING ARM 63 GEAR PULLEY
32 ECCENTRIC PIVOTS FOR GUARD
