8 9www.donperusa.com Phone: (844) 366-7371 Email: sales@donperusa.com
WARNING: Unpalletizing requires lifting. Two or more personnel should
remove the machine from its packaging and place it in its final operating
location. Failure to do so may result in severe injury or damage.
CAUTION: Do NOT over tighten the side panel screws as this could strip the
plastic anchor points for the screws.
U M
1. To remove all sides and cover of shipping box, unfold all tabs on the shipping box
from their closed position to the open position using a at-head screwdriver, and
a hammer if needed.
2. Remove plastic wrapping from around the machine.
3. Being careful not to scratch or dent the machine panels, remove both side panels
with a phillips-head electric screw driver.
4. On the bottom of the machine there are 2 stabilizing bolts securing the machine
to the bottom of the shipping pallet/box. Using a #12 wrench and a #12 ratchet
carefully remove both bolts.
5. Reattach both side panels using the phillips-head electric screw driver.
6. Prepare the area where the machine will be placed.
7. Place the machine in its nal location according to the Installation Requirements
U I P
1. Remove all packaged parts and accessories from your machine.
2. Organize items on a clean table or operating area using the checklist below.
UNPACKING
Hopper Lids (2)
Drip Tray (1)
Drip Tray Cover (1)
Spare Parts Kit
O-ring for Piston (4)
H-Seal (1)
Supporting Sleeve (2)
O-Ring for Dispenser Door(2)
Rear Seal (2)
Food Grade Lube
Feed Tube (2)
O-ring for feed Tube (4)
Assembled Dispenser Door
Dispenser Door
Outer Draw Valve (2)
Middle Draw Valve (1)
O-ring for outer Draw Valve (4)
H-Seal (1)
Dispensing Handles (3)
Pin for Handles (1)
Supporting Sleeve (2)
O-Ring for Dispenser Door(2)
User Manual
UNPACKING
