11. I/O CONNECTOR LAYOUT AND DESCRIPTION
Note: The control should be tested prior to connecting any external devices, sensors, push pads, or locks.
Common +
O
One Way
Partial Open
Hold Open
Reset
24 VDC
24 VDC-R
Common +
Safety
X
X
X
X
X
X
X
X
X
X
1
2
3
4
5
6
7
8
9
10
J6
Common +
Emergency Open
Common +
Ratchet
Common +
Activation
Common +
Breakout
Common +
Night Mode
X
X
X
X
X
X
X
X
X
X
1
2
3
4
5
6
7
8
9
10
J7
Installation Manual
DC One V3
321 VZ County Road 4500 · Ben Wheeler, TX 75754 · Phone: 800.437.3667 · Fax: 800.356.8858 · DoorControlsUSA.com
7
Rev050819
J6 - Safety Beams - Pins 7 to 10
· Activates the door except when in the closed position
· 24 VAC power to safety beam module
· Red LED is on when active
J7 - Special Modes
Emergency Open
Activates the door during all
modes
Green LED is on when active
Ratchet
Activates door and stays
open until ratchet is pressed
again
Does not activate during o,
one way, or night mode
Green LED is on when active
Activation
Activates the door during all
modes
Green LED is on when active
Breakout
Stops door motion
Software selectable polarity
(NO/NC)
Red LED is on when active
Night Mode
Disables inner and outer
sensors in closed position
Door activates with
emergency open and activa-
tion input only (pin 2 or 6 of
J7)
Yellow LED is on when active
Compatible with DC position
switches
5PSW1 - 5 position knob
5PSW2 - 5 position key
6PSW1 - 6 position knob
6PSW2 - 6 position key
O
Disables ratchet, inner
sensor, and outer sensor
inputs
Locks door if a lock is present
Control on LED will turn o
One Way
Disables outer sensor in the
closed position
Yellow LED is on when active
Partial Open
The door will not fully open
Width is adjustable in menu
Yellow LED is on when active
Hold Open
Holds the door in the open
position
Green LED is on when active
Reset
Resets position values
The door will relearn on next
activation
Yellow LED is on when active
J6 - Multifunction Switch - Pins 1 to 6
