Installation Manual
DC One V3
321 VZ County Road 4500 · Ben Wheeler, TX 75754 · Phone: 800.437.3667 · Fax: 800.356.8858 · DoorControlsUSA.com
11
Rev050819
Door Breaking
· Should only be turned on for heavy doors
· Adjustable in program mode only
Handing
· Sets the door to either right- or left-hand
mode
· Adjustable in program mode only
Lock Type
· Sets the lock type to either secure or safe,
auto detects DC One lock
· Adjustable in program mode only
Breakout Polarity
· Congures breakout for either normally
open (NO) or normally closed (NC)
contacts
· Adjustable in program mode only
Lock Delay
· Set to ON if the door has an electric lock.
This allows the control to monitor the lock
position. When the Lock Delay is set to on
and the controller receives an activation
the lock will disengage, send a signal to
the controller and the door will open.
Note: If the lock disengages and the door
will not move the signal wires or lock switch
may be faulty. For troubleshooting: try turn
ingthelockdelayo.
· Adjustable in program mode only
Load Factory Defaults
· Pressing the program key will reset all
settings to factory default
· Adjustable in program mode only
Sensor Monitoring
· Select what sensors to monitor
· None · Inner
· Outer · Both
RIGHT HAND DOOR
FAIL SECURE LOCK
BREAKOUT POLARITY NO
LOCK DELAY OFF
LOAD FACTORY DEFAULT
SENSOR MONITORING
DOOR BRAKING OFF
14. PART NUMBERS
**Optional
15. TECHNICAL SPECIFICATIONS
16. WARRANTY TERMS
1 Year from date of purchase form Door Controls USA, Inc.
Control DC-09-2904-04
Motor DC10200
Power Cord DC-09-3114
Transformer DC-09-3116
Belt 9-99-0008
Lock** DC10255/DC10256
Power Input 120 Volts AC, Single Phase
Power Consumption 150W Max
Secondary Power Supply 24 Volt, 1A Max.
Drive Train Molded Brushed DC Motor with Gear Reduction Assembly
Control Microprocessor Controller
Maximum Door Weight 400 lbs (200 lbs per panel for bi-part)
Operating Environment -4F to 158F (-20C to +70C) 30% to 85% Relative Humidity
