Door Controls DC One - Page 10

 Open Speed
· Ranges from 5 to 100%
 Close Speed
· Ranges from 5 to 100%
 Open Check Speed
· Ranges from 5 to 100%
 Close Check Speed
· Ranges from 5 to 100%
 Boost Speed
· Acceleration from a stopped position to
check the speed
· Ranges from 5 to 100%
 Open Deceleration
· Adjusts the transition between open and
open check
· Higher values cause a more abrupt change
between the two speeds
· Ranges from 0 to 255
 Close Deceleration
· Adjusts the transition between close and
close check
· Higher values cause a more abrupt change
between the two speeds
· Ranges from 0 to 255
 Open Torque
· Ranges from 0 to 100%
· Not adjustable. They are set during auto
learn sequence and are readjusted
anytime the control is reset.
 Close Torque
· Ranges from 0 to 100%
· Not adjustable. They are set during auto
learn sequence and are readjusted
anytime the control is reset.
 Open Check Torque
· Ranges from 0 to 100%
· Adjustable. This is where we set the cont
roller power to move the door throughout
the open check cycle. If the door will not
open completely. This is where to start.
Turn this up 10% at a time till the door
moves through the cycle without hesitation.
 Close Check Torque
· Ranges from 0 to 100%
· Adjustable. This is where we set the con
troller power to move the door throughout
the close check cycle. If the door will not
close completely. This is where to start.
Turn this up 10% at a time till the door
moves through the cycle without hesitation.
 Open Check Size
· Ranges from 3" to 18"
· Adjustable in program mode only
 Close Check Size
· Ranges from 3" to 18"
· Adjustable in program mode only
 Reduced Open Size
· Ranges from 12" to 72" in 4" increments
· Adjustable in program mode only
 Hold Open Time
· Ranges from 1 to 30 seconds
· Adjustable in program mode only
OPEN SPEED
056.3%
CLOSE SPEED
020.9%
OPEN CHECK SPEED
012.0%
CLOSE CHECK SPEED
012.0%
BOOST SPEED
030.1%
OPEN DECELERATION
030
CLOSE DECELERATION
030
Installation Manual
DC One V3
321 VZ County Road 4500 · Ben Wheeler, TX 75754 · Phone: 800.437.3667 · Fax: 800.356.8858 · DoorControlsUSA.com
10
Rev050819
OPEN TORQUE
072.0%
CLOSE TORQUE
072.0%
OPEN CHECK TORQUE
014.8%
CLOSE CHECK TORQUE
014.8%
OPEN CHECK SIZE 10”
CLOSE CHECK SIZE 05”
HOLD OPEN TIME 3s
HOLD OPEN TIME 3s
