Door Position
This is a status only screen that gives the
following information:
· Encoder Counts - shows the actual
encoder count relative to door position
· Encoder Pulses - toggles between upper
and lower case as encoder pulses are
received
· Status - toggles between upper and lower
case as status changes
act/ACT - Activation
sf/SF - Safety
ro/RO - Reduced Open
bo/BO - Breakout
· State - shows the state of the controller
0 - Closed
1 - Opening
2 - Open Deceleration
3 - Open Check
4 - Open
5 - Closing
6 - Close Deceleration
7 - Close Check
B - Boost Mode
L - Learn Mode
O - Obstruction
Life Cycle Counter
· Indicates the total number of door cycles
on the control
· Non-resettable
Trip Cycle Counter
· Indicates the number of cycles since the
trip counter was last reset
Trip Counter Reset
· Resets the trip counter
· Resetable in program mode only
Faults Detected
· Lists the fault that the control is currently
under
· None
· Broken or Loose Belt
· Jammed Door
· Obstruction Lockout
· Control will remain in hold
open after 3 consecutive
obstruction errors
· Control must be reset or
turned o to clear error
· O is preferable to prevent
to relearn cycle after a reset
· Sensor Monitor
Learn Torque
· Ranges from 5 to 100%
Learn Open Speed
· Ranges from 5 to 100%
Learn Close Speed
· Ranges from 5 to 100%
· Sensor monitoring
Sensor Monitoring
· 1 None
· 2 Int
· 3 Ext
· Adjustable in program mode only
· Learn torque set to normal door
Language
· English
· Spanish
· Adjustable in program mode only
Phone Number
Software Version
DOOR POSITION 00258
act sf ro bo 0 X Y
LIFE CYCLE COUNT
00000000
TRIP CYCLE COUNT
00000000
RESET TRIP COUNTER
Installation Manual
DC One V3
321 VZ County Road 4500 · Ben Wheeler, TX 75754 · Phone: 800.437.3667 · Fax: 800.356.8858 · DoorControlsUSA.com
9
Rev050819
FAULTS DETECTED
NONE
LEARN TORQUE
020.5%
LEARN OPEN SPEED
014.8%
LEARN CLOSE SPEED
014.8%
SENSOR MONITORING
1 NONE
MENU EN ESPANOL
DOOR CONTROLS USA
800-437-3667
DC ONE V3
FIRMWARE V-X.XX
