Operation Section
54
Lift Truck Operation
Be sure no one is working on or near the lift truck.
Keep the lift truck under control at all times.
Reduce speed when maneuvering in tight quarters
or when braking over a rise.
Do not allow the lift truck to overspeed downhill.
Use the service brake pedal to reduce speed when
traveling down hill.
NOTICE
Do not move the directional control forward/reverse
switch from one direction to the other(plug) when
the drive wheels are off the ground and rotating at
full speed.
Damage can occur to the control panel.
Adjust the operator’s seat.
1. Fasten the seat belt.
2. Move the directional control forward/reverse
switch into the NEUTRAL position, if it is not
already in this position.
3. Turn the key switch to the ON position. Raise
the attachments.
4. Move the directional control forward/reverse
switch to the direction of travel.
5. Release the service brake pedal.
To Next Page
