Operation Section
G 47
Relation between battery charge level and
number of visualized bars
Table 1 : Case of a generic system
DISPLAY
INDICATION
BATTERY CHARGE
LEVEL
No segments Discharged battery
1 flashing segment 10 %
1 segment 20 %
2 segments 30 %
3 segments 40 %
4 segments 50 %
5 segments 60 %
6 segments 70 %
7 segments 80 %
8 segments 90 %
9 segments Full charged battery
Table 2 : Case of an 36V system (BC25S – 36V)
BATTERY CHARGE
LEVEL
BATTERY VOLTAGE
[ V ]
Discharged battery Voltage < 34.5 V
10 % 34.5 V ÷ 35.1 V
20 % 35.1 V ÷ 35.5 V
30 % 35.5 V ÷ 35.9 V
40 % 35.9 V ÷ 36.2 V
50 % 36.2 V ÷ 36.5 V
60 % 36.5 V ÷ 36.8 V
70 % 36.8 V ÷ 37.1 V
80 % 37.1 V ÷ 37.4 V
90 % 37.4 V ÷ 37.6 V
Full charged battery Voltage > 37.6 V
Table 3: Case of a 48V system (B(C)25S – 48V)
BATTERY CHARGE
LEVEL
BATTERY VOLTAGE
[ V ]
Discharged battery Voltage < 45.6 V
10 % 45.6 V ÷ 46.4 V
20 % 46.4 V ÷ 47 V
30 % 47 V ÷ 47.6 V
40 % 47.6 V ÷ 48.2 V
50 % 48.2 V ÷ 48.7 V
60 % 48.7 V ÷ 49.2 V
70 % 49.2 V ÷ 49.7 V
80 % 49.7 V ÷ 50.1 V
90 % 50.1 V ÷ 50.4 V
Full charged battery Voltage > 50.4 V
Table 4 : Case of a 80V system
BATTERY CHARGE
LEVEL
BATTERY VOLTAGE
[ V ]
Discharged battery Voltage < 75.7 V
10 % 75.7 V ÷ 76.5 V
20 % 76.5 V ÷ 77.3 V
30 % 77.4 V ÷ 78.2 V
40 % 78.3 V ÷ 79.1 V
50 % 79.2 V ÷ 80.0 V
60 % 80.1 V ÷ 80.9 V
70 % 81.0 V ÷ 81.8 V
80 % 81.9 V ÷ 82.7 V
90 % 82.8 V ÷ 83.6 V
Full charged battery Voltage > 83.6 V
G
G
Table 5 : Contraction for dot matrix display
Alarm Code
Display
Code
Description Contraction
17 Main breaker fault
CONTACTOR
FAULT
60
Battery/inverter
mismatch
BATT MISMATCH
61
Blocking
Overtemperature of
right motor (over 165ଇ)
R-MOTOR
SHUTDOWN
62
Blocking
Overtemperature of left
motor (over 165ଇ)
L-MOTOR
SHUTDOWN
65
Blocking
Overtemperature of pump
motor (over 165ଇ)
P-MOTOR
SHUTDOWN
76 Pump motor Encoder
P-MOTOR
ENCODER.
77
Wrong right traction
motor thermal switch
R-M TEMP
SENSOR
78
Wrong left traction
motor thermal switch
L-M TEMP
SENSOR
79
Wrong pump motor
thermal probe
P-M TEMP
SENSOR
80
Wrong right traction
module thermal probe
R-INV T SENSOR
81
Wrong left traction
module thermal probe
L-INV T SENSOR
82
Wrong pump module
thermal probe
P-INV T SENSOR
83 CRC fault CRC FAULT
84 Bank CRC restored CRC RESTORED
A
Capacitors not
charged : fast charge
FAST CHARGE
A
Trans.precharge in
Short / Cap. Too
charged
TOO CHARGED
A
Capacitors not
charged :
slow charge
CAP SLOW
CHARGE
A
Capacitors not
charged : time out
TIME OUT
CHARGE
