Power Train Disassembly & Assembly
NOTE : The value calculated in step 6 or 7 is the
thickness of the new shim pack that will be installed.
Refer to the following examples.
8. Install the drive pinion, bearing cage and new shim
pack into the carrier.
26
Examples: Inches mm
1. Old Shim Pack Thickness .030 .76
Old PC Number, PC +2 inches (+0.05 mm) -.002
-.05
Standard Shim Pack Thickness .028 .71
New PC Number, PC +5 inches (+0.13 mm) +.005 +.13
New Shim Pack Thickness 0.033 0.84
2. Old Shim Pack Thickness .030 .76
Old PC Number, PC -2 inches (-0.05 mm) +.002
+.05
Standard Shim Pack Thickness .032 .81
New PC Number, PC +5 inches (+0.13 mm) +.005
+.13
New Shim Pack Thickness 0.037 0.94
3. Old Shim Pack Thickness .030 .76
Old PC Number, PC +2 inches (-0.05 mm) -.002
-.05
Standard Shim Pack Thickness .028 .71
New PC Number, PC -5 inches (-0.13 mm) -.005
-.13
New Shim Pack Thickness 0.023 0.58
4. Old Shim Pack Thickness .030 .76
Old PC Number, PC -2 inches (-0.05 mm) +.002
+.05
Standard Shim Pack Thickness .032 .81
New PC Number, PC -5 inches (-0.13 mm) -.005
-.13
New Shim Pack Thickness 0.027 0.68
NOTE : Drive pinions and ring gears MUST be replaced as fully matched sets.
