Vehicle Systems Disassembly & Assembly 29
Steering Wheel
Remove & Install Steering Wheel
1. Remove cap (1) from the steering wheel.
2. Remove nut (2) and washer (3) from the steering
wheel shaft. Put location marks on the steering
wheel and the steering wheel shaft for installation
purposes.
3. Remove the steering wheel from the shaft.
NOTE: Use the following steps to install the
steering wheel.
4. Put the steering wheel on the steering wheel
shaft in its original position.
5. Install washer (3) and nut (2). Tighten nut (2) to a
torque of 80 ± 7 N•m (60 ± 5 lb•ft).
6. Install cap (1).
1
2
3
