Operating & Maintenance Manual OPERATION
32 Book: 46551819 (2-11-2011) Rev B
BEFORE TOWING
WARNING
!
Failure to follow these instructions CAN cause severe injury or death.
• Assure tow vehicle has towing capacity for weight of this unit as stated on general data
decal.
• Position the tow vehicle to align its hitch with the pintle eye or coupler of the
compressor.
• Engage the parking brake and chock the tires of the tow vehicle.
• Stand to the side and ensure pin is FULLY inserted (secure) in tube of jack.
• Crank jack to seat pintle eye or coupler onto hitch. Latch and lock hitch. Cross safety
chain(s) under drawbar. Attach to vehicle.
• Crank jack to raise pad off the ground. Pull pin from tube of jack.
• Fold jack handle down and forward. Swing up jack tube and FULLY insert pin in tube.
• Remove tire chocks.
• Test brakes, if so equipped.
• Test lights (running, stop, and turn signals).
WARNING
!
Always raise (or remove) jack for maximum ground clearance before towing.
