OPERATION Operating & Maintenance Manual
Book: 46551819 (2-11-2011) Rev B 33
Setting Up (All Units)
• Position as level as possible. The design of these units permits a 15 degree sidewise
limit on out-of-level operation.
• When the unit is to be operated out-of-level, it is important:
1. To keep the engine crankcase oil level near the high level mark (with the unit level).
2. To have the compressor oil level gauge show no more than mid-scale. Do not overfill
either the engine crankcase or the compressor lubricating oil system.
3. The side doors must be closed to maintain a cooling air path and to avoid recirculation
hot air.
Towing
WARNING
!
Failure to follow these instructions CAN cause severe injury or death.
Disconnect
• Engage tow vehicle parking brake.
• Chock tires of compressor.
• Set the vehicle parking brake. Chock wheels of unit.
• Standing to the side, remove pin from tube of jack.
• Disconnect safety chains. Crank jack to raise eye or coupler from hitch. Tow vehicle
can be moved.
UTILITY PACKAGE SET-UP (no running gear)
This unit must be located on vehicle bed to allow access for normal servicing and
maintenance.
The air going into the inlet must be relatively free of oil, dirt, soot and other debris. It must be
no more than 10 degrees F. (5 degrees C) over the ambient temperature.
