MAINTENANCE Operating & Maintenance Manual
Book: 46551819 (2-11-2011) Rev B 43
Air Cleaner
Weekly squeeze the rubber valve (precleaner dirt dump) on each air cleaner housing to ensure
that they are not clogged.
The optional air filters restricted sensor will automatically reset after the main power switch is
turned to “OFF.”
To service the air cleaners on all units proceed as follows:
1. Loosen the 3 latches on the sides of the air cleaner cover.
2. Remove air cleaner body.
3. Pull out air cleaner element.
4. Pull out safety element if installed.
5. Install new filters in air cleaner body.
6. Re-install cover on air cleaner body.
7. Close the 3 latches after securing to air cleaner body.
Make sure that all clamps and flange joints are tight.
Make sure the pre-cleaner dirt dump is pointed within 30° of down.
Gauges
The instruments or gauges are essential for safety, maximum productivity and long service life
of the machine. Inspect the gauges and test any diagnostic lamps prior to start-up. During
operation observe the gauges and any lamps for proper functioning. Refer to Operating
Controls, for the normal readings.
Fuel Tank
CLEAN fuel in the fuel tanks is vitally important and every precaution should be taken to
ensure that only clean fuel is poured or pumped into the tank.
When filling the fuel tank on this unit, by methods other than a pump and hose, use a CLEAN
non-metallic funnel.
Battery
Keep the battery posts-to-cable connections clean, tight and lightly coated with a grease. Also
the electrolyte level in each cell should cover the top of the plates. If necessary, top-up with
clean distilled water.
