Doosan DE08TS - Engine Assembly View

DE08TS Diesel Engines General Information
Engine assembly views
a. DE08TS
1. Flywheel housing 8. Oil filler cap 16. Water pump
2. Intake manifold 9. Oil level gauge 17. Exhaust manifold
3. Breather 10. Oil pan 18. Cylinder head cover
4. Air pipe 11. Oil drain plug 19. Crank shaft pulley
(Air cleaner to intake manifold) 12. Oil filter 20. Vibration damper
5. Fuel filter 13. Fuel injection pump 21. Oil cooler
7. Air compressor (if equipped) 14. Air compressor pulley 22. Starter
15. Thermostat
