Dorma ED 100 User Manual

45
32
45
150
106120 12095
451
155
B
D
A
C
120100
32
63
Maximum lintel depth ± 30 mm
Ø 6.6
Upper edge of door
Upper edge of door
Space for cable inlet
Door with rebate
Installation on hinge side with 25 mm pivot pin
Axle extension ED 100 ED 250 A B C D
Standard (9 mm)
31 mm 63 mm 22 mm 54 mm
20 mm
51 mm 83 mm 42 mm 74 mm
30 mm
61 mm 93 mm 52 mm 84 mm
60 mm
91 mm 123 mm 82 mm 114 mm
90 mm ---
121 mm 153 mm 112 mm 144 mm
ED 100, ED 250
—
10 DORMA

Dorma ED 100 Specifications

General

Adjustable Closing Speed	Yes
Latching Speed	Adjustable
Type	Electromechanical
Power Supply	230 V AC, 50 Hz
Fire Rated	Yes
Backcheck	Adjustable
Delayed Action	Adjustable
Hold-Open Function	Yes
Finish	Silver
