Dorma ED 100 User Manual

3.14 Torque Overview
ED 100
Installation type Lintel mounting on hinge side,
pull version of slide channel
Lintel mounting on opposite hinge side,
push version of standard arm /
push version of slide channel
minimum maximum minimum maximum
Closer size pursuant to EN 1154 EN 2 EN 4 EN 2 EN 4
Manual closing torque (Nm)*** 13 34 13 37
Automatic closing torque (Nm)** 20 FE: 150/LE: 67 20 FE: 150/LE: 67
Manual opening torque (Nm) 30 50 35 55
Automatic opening torque (Nm)** 20 FE: 150/LE: 67 20 FE: 150/LE: 67
Opening torque of manually activated
Power Assist Function (Nm) *
23 23 23 23
ED 250
Installation type Lintel mounting on hinge side,
pull version of slide channel
Lintel mounting on opposite hinge side,
push version of standard arm /
push version of slide channel
minimum maximum minimum maximum
Closer size pursuant to EN 1154 EN 4 EN 6 EN 4 EN 6
Manual closing torque (Nm)*** 26 65 26 70
Automatic closing torque (Nm)** 20 FE: 150/LE: 67 20 FE: 150/LE: 67
Manual opening torque (Nm) 55 85 60 90
Automatic opening torque (Nm)** 20 FE: 150/LE: 67 20 FE: 150/LE: 67
Opening torque of manually activated
Power Assist Function (Nm) *
23 23 23 23
FE With installed Full-Energy or Fire Protection Upgrade Card,
LE Low-Energy basic device without Upgrade Card
* If Power Assist support set to maximum, effective from an opening width of approx. 3°.
** The torque is available in the event of automatic opening in automatic mode.
*** In the push version of the slide channel installation type, the forces reduce by approx. 33%
4. Preparing for Installation
1. Use the following data to check whether the device meets the necessary requirements.
You can get started with the installation process if the parameters have been complied with.
Standard arm 225 29271xxx Standard arm 500 29272xxx Pull version of slide channel 29275xxx Push version of slide channel 29275xxx Pull version of slide channel CPD 29276xxx
Axle extension
20 mm 29278301 30 mm 29278001 60 mm 29278101 90 mm 29278201
ED 100 EN 2 – 4 29222301
F F/300 F o F F F F x
ED 250 EN 4 – 6 29202301
F F o o F F F F F/350
EN 4 – 5 29202303
o o F o F F F F F/350
EN 4 – 6 29202302
o o F o F F F F F/350
o Suitable for use on standard doors.
F Suitable for use on standard,
fire and smoke doors.
2. Depending on the installation situation, select the
corresponding drilling pattern on pages 9 – 14.
3. Drill the holes shown in the drilling pattern in the door
leaf and frame / wall.
F/xxx Suitable for use on standard, fire and smoke doors; the lintel
depth is limited to xxx mm.
x Combination not possible
ED 100, ED 250
—
8 DORMA

Dorma ED 100 Specifications

General

Adjustable Closing Speed	Yes
Latching Speed	Adjustable
Type	Electromechanical
Power Supply	230 V AC, 50 Hz
Fire Rated	Yes
Backcheck	Adjustable
Delayed Action	Adjustable
Hold-Open Function	Yes
Finish	Silver
