Dorma ED 100 User Manual

3.13 Technical Data
Operating conditions
Ambient temperature - 15 – + 50° C
Suitable for dry rooms only Relative humidity max. 93%,
non-condensing
Power supply 230 V AC +/- 10%, 50 Hz
Protection class IP 20
General
Dimensions (WxHxD) 685 x 70 x 130 mm
Min. distance between hinges
in double-leaf systems
1,400 mm
Min. distance between hinges
in double-leaf systems with
ESR
1,450 mm
Min. distance between hinges
in double-leaf systems with
VARIO cover
1,500 mm
Drive weight 12 kg
Power supply for external
consumers
24 V DC +/- 5%, 1.5 A
Door opening angle Max. 95° – 110°, depending
on installation type
Fuse provided by the customer 16 A
Operating noise Max. 50 dB(A)
Inputs
Connectors / terminals Max. 1.5 mm
2
Potential-free activator Inside and outside
(NO contact)
Night/Bank (intercom system) 8 – 24 V DC / AC + 5%
Night/Bank (key switch) NO contact / NC contact
Safety sensor Hinge side and opposite
hinge side (NC contact)
Safety sensor test signal Hinge side and opposite
hinge side
Deactivation of drive function
(lock switch)
NC contact /
NO contact
Outputs
Connectors / terminals Max. 1.5 mm
2
Potential-free status contact Door closed, Door open
Malfunction,
Door closed and locked
Integrated functions
Latching action Force adjustable
Hold-open time in the event of
automatic opening
0 – 30 seconds
Night/Bank hold-open time 0 – 30 seconds
Hold-open time in the event of
manual opening
0 – 30 seconds
Blocking behavior Reversing / door closer
function
Electric strike’s delayed
opening for locking mechanism
0 – 4 seconds
Locking device feedback Motor lock
Wind load control Up to 150 N
Voltage-independent braking
circuit
Adjustable with
potentiometer
LED status indicator Green
Red
Yellow
– Operating voltage control
– Malfunction information
– Service interval display
Integrated program switch Off, Automatic, Permanent
open, Exit (only in the event
of single-leaf systems)
User interface with information
display
Status indicator and
parameterization
Slot for
DORMA Upgrade Cards
Extension of range of
functions
Interface update Firmware update
TMP – Temperature
Management Program
Overload protection
IDC – Initial Drive Control Driving phase optimization
Cycle counter 0 – 1,000,000
(sensibly divided)
Power Assist Function Servo support in the event of
manual opening
Push & Go Function Door opens when moved
manually by 4°
ED 250
Max. power consumption 240 W
Closing force EN 4 – 6, infinitely variable
Max. door leaf weight
up to a lintel depth of 300 mm
250 kg up to a door leaf
width of 1,400 mm
190 kg with a door leaf
width of 1,600 mm
Max. door leaf weight for a
lintel depth of 301 – 500 mm
160 kg
Door leaf width 700 – 1,600 mm
Door leaf width for fire
protection
700 – 1,400 mm
Max. opening speed **60° (27°*)/second
Max. closing time **60° (27°*)/second
Axle extension 20/30/60/90 mm
Lintel depth for slide channel
(CPD)
+/- 30 mm (- 60 mm)
Lintel depth for standard arm 0 – 500 mm
ED 100
Max. power consumption 120 W
Closing force pursuant to EN
1154
EN 2 – 4, infinitely variable
Max. door leaf weight
up to a lintel depth of 300 mm
100 kg
Door leaf width 700 – 1,100 mm
Max. opening speed **50° (27°*)/second
Max. closing time **50° (27°*)/second
Axle extension 20/30/60 mm
Lintel depth for slide channel
(CPD)
+/- 30 mm (- 60 mm)
Lintel depth for standard arm 0 – 300 mm
* Values in brackets indicate the max. speed in low-energy
mode without a Full-Energy
or Fire Protection Upgrade Card.
** Automatically limited pursuant to EN 16005 or DIN
18650, BS 7036-4 and ANSI 156.19 depending on the
door leaf weight.
ED 100, ED 250
—
7DORMA

Dorma ED 100 Specifications

General

Adjustable Closing Speed	Yes
Latching Speed	Adjustable
Type	Electromechanical
Power Supply	230 V AC, 50 Hz
Fire Rated	Yes
Backcheck	Adjustable
Delayed Action	Adjustable
Hold-Open Function	Yes
Finish	Silver
