Dorma ED 100 User Manual

Contents
Page
1. General Information .............................................................................................................2
2. Safety ................................................................................................................................. 3
3. Product Description .............................................................................................................4
4. Preparing for Installation ......................................................................................................8
5. Installing the Drive ...............................................................................................................15
6. Connecting Accessories ........................................................................................................ 26
7. Commissioning .................................................................................................................... 27
8. Upgrade Cards..................................................................................................................... 28
9. Parameterization / Service .................................................................................................... 30
10. Diagnosis / Troubleshooting ...................................................................................................37
11. Error Messages .................................................................................................................... 39
12. Information for the Facility Drive ...........................................................................................42
1. General Information
Keep the documents in a safe place and hand them over to
the new facility drive if you transfer the system.
Symbols used in these instructions
 REMARK A remark draws attention to important
information which may make work
easier for you.
 NOTE A note warns of potential damage to
the device and explains how it can be
avoided.
ATTENTION This symbol points out dangers which
may result in personal injury or even
death.
 Unless specified otherwise,
all dimensions are given in mm.
“Translation of the original instructions”
ED 100, ED 250
—
2 DORMA

Dorma ED 100 Specifications

General

Adjustable Closing Speed	Yes
Latching Speed	Adjustable
Type	Electromechanical
Power Supply	230 V AC, 50 Hz
Fire Rated	Yes
Backcheck	Adjustable
Delayed Action	Adjustable
Hold-Open Function	Yes
Finish	Silver
