dormakaba 9000 Series MLR Installation Instructions
95071186 01-2021Exit Device
9
MLR Spec Label
MATERIAL:
WHITE PERMANENT ADHESIVE LABEL
BY DATENO.REVISIONS
DWG. NO.
CHKD BY: DATE:
DATE:
DRAWN BY:
T
O
L
E
R
A
N
C
E
DESCRIPTION:
COIL WIDTH:
MATERIAL:
WEIGHT:
SCALE:
FINISH:
PROGRESSION:
ANGLES---------±2˚
FRACTIONS-------±1/32
DECIMALS .XX-----±.015
DECIMALS .XXX----±.010
UNLESS NOTED OTHERWISE
MLR-Label
MLR Spec. Label - Place in end of rail
1"=1"T .A.0 7-25-13
S.M. 2-1-2020
Specifications:
Electrical input requirements:
24Vdc +10% Filtered and regulated
power supply; ie: dormakaba
DKPS-2A.
The unit may also be powered by the
dormakaba ED900 operator.
Current: .88 max. inrush,
400mA max. hold
Non polarized leads
-
Update Inst. 1 TA 1-6-14
Update Inst. 2 TA 1-7-2021
2 "
2"
. MLR Spec label
