1. General
ED 100 and ED 250 are electromechanical automatic swing door
drives and are used for the automatic opening and closing of
swing doors.
Please retain these documents and forward them to the new
owner in case the system is passed on.
Symbols used in this manual
î NOTE A note points to important information that
will facilitate your work.
WARNING Indicates risks that may lead to physical
injury or death.
2. Safety
This documentation contains important instructions for the
safe operation. Read these instructions before you use the door
system.
In order to ensure your safety please follow all the enclosed
instructions.
Intended use
ED 100 and ED 250 are electromechanical automatic swing door
drives and are used exclusively for the automatic opening and
closing of swing doors in the interior with a maximum door panel
weight of 160 or 400 kg.
Limitation of liability
ED 100 und ED 250 may be used only for their intended
purpose.
Unauthorized modifications to the door system will exclude any
liability by dormakaba Deutschland GmbH for any resulting
damage. We will not be liable for the use of accessories that are
not approved by dormakaba.
Safety instructions
Work on electrical equipment must be performed by
qualified electricians only.
Never allow children to play with the ED 100/250 or its
control and regulating devices.
Keep remote controls out of the reach of children.
Never insert a metal object into the openings of the door
system. Otherwise, there will be the risk of an electrical
shock.
The ED 100/250 must be protected against water and other
liquids.
Safety glass must be used for glass door panels.
Only properly qualified persons may open the mains
connection unit.
Deenergize the ED 100/250 before removing the protective
cover.
Danger points on closing edges
There is a risk of crushing, squeezing and drawing at auto-
matic doors at the various closing edges.
Counter closing edge
Secondary counter
edge
Main closing edge
Danger posed by slide rail lever and arms assembly
There is a risk of squeezing and crushing on slide rail levers
and arms assemblies.
Residual risk
Depending on the structural conditions, the type of door and
protection, it is not possible to rule out residual risks (e.g. slight
bruising, limited impact and the risk to unsupervised children).
The danger point on any (even manually operated) swing door at
the secondary closing edge is generally known to all users of a
door. It is not controllable by the drive manufacturer and from
a design and functional point of view a protection is often not
possible.
A possible suitable crush protection (e.g. rubber or textile cover)
is available in specialist shops and not part of the scope of
delivery.
