6. Troubleshooting
Functional errors may have many causes.
The errors are often caused by environmental conditions and
the drive unit will therefore try to detect and to react to them
accordingly. The drive unit stops the current function and starts
again after a waiting period or a new pulse. If it does not work,
the automatic function will be shut off and an error message will
be output.
This is indicated by a red LED on the program switch.
The display flashes or lights permanently and indicates an error
that need to be eliminated by the dormakaba Service.
The following options are available to reset error messages:
1. Switch the program switch to the OFF position.
2. Mains reset. Switch off the power switch.
Restart after 10 seconds.
The cause should be analyzed and eliminated before an error
message is acknowledged.
Self-help in case of errors
In case errors occur during the operation
please check the following:
• Mains voltage available?
• Is the power switch on?
• Can the door be freely moved?
• Is the door manually locked, shutdown
(lock switch) activated?
• Has the correct function been selected with the program
switch?
• Is the turning range of the door free from obstacles?
• Has the hold-open system been triggered?
Please contact the Service Department if these points are okay
and the doors system still does not work.
7. Disassembly, recycling and disposal
The disassembly is carried out in the reverse order of the installa-
tion manual and must be carried out by qualified personnel.
De-energize the door system before disassembling the door
system.
Dispose the product in an environmentally friendly
manner. Electronic parts and batteries may not be
disposed via the general trash.
Take them to an appropriate collection point for
disposal.
Always comply with the applicable national legal provisions.
8. EC Declaration of conformity
dormakaba Deutschland GmbH,
DORMA Platz 1, 58256 Ennepetal
hereby declares that the products
ED 100, ED 250, ED 900, ED 250 PA
comply with the provisions of the named EC Directive(s) and that
the standards and/or technical specifications referred to in the
following have been applied.
Directive: 2014/30/EC Electromagnetic
compatibility
The technical documentation is available from the Product Com-
pliance Manager: product-compliance.dach@dormakaba.com.
Harmonized European standard, national rule:
EN 13849-1 EN ISO 12100 EN 16005
EN 60335-1 EN 60335-2-103 EN 60950-1
EN 61000 - 6 - 2 EN 61000 - 6 - 3 EN 61000 - 3 - 2
EN 61000 - 3 - 3
9. EC Declaration of incorporation
dormakaba Deutschland GmbH,
DORMA Platz 1, 58256 Ennepetal
hereby declares that the incomplete machine
ED 100, ED 250, ED 900, ED 250 PA
complies with the following basic requirements of the Machine
Directive (2006/42/EC)- Appendix I, Article:
1.1.3, 1.1.5, 1.2.1, 1.2.3, 1.2.5, 1.2.6, 1.3.1, 1.3.2, 1.3.3,
1.3.4, 1.3.7, 1.3.8.1, 1.3.9, 1.5.1, 1.5.2, 1.5.4- 1.5.10, 1.5.16,
1.6.1, 1.6.2, 1.6.3, 1.6.4, 1.7.1.1, 1.7.3, 1.7.4
The incomplete machine also complies with all relevant provisi-
ons of the directives 2014/35/EC und 2014/30/EC.
It may be installed and operated in automatic door systems in
accordance with the Machine Directive if the manufacturer of the
system ensures that all requirements of the Machine Directive are
complied with and if the manufacturer issues a EC Declaration of
conformity.
The special technical documents have been prepared and are
available from the Product Compliance Manager:
product-compliance.dach@dormakaba.com.
Upon a substantiated request, they will be electronically trans-
mitted to the national authorities.
