Dormakaba ED100 Owner's Manual

13
ED50/ED100/ED250 09-2021DL4615-013
dormakaba ED50/ED100/ED250 Owner's Manual
Overhead concealed header
Chapter 6
. Low energy power operated swing door (ANSI/BHMA .)
.. Review safety related items and perform checks
periodically as noted.
TIPS AND RECOMMENDATIONS
Perform these checks while traffic is restricted.
. Housekeeping:
• Check door area for tripping or slipping hazards.
• Make sure all hardware and overhead covers are
properly secured.
• There should be no bulletin boards, literature racks,
merchandise displays, or other attractions in the
door area that would interfere with the use of the
door or encourage people to stop and stand in the
door area.
. Check all doors for damage.
. Door closing force:
• Force to prevent the door from closing should not
exceed  pounds measured with a force gauge.
. Door safety signage:
• Refer to Chapter  for door safety signage
requirements. Chapter  documents safety
information (daily safety check) and annual
compliance inspection labels requirements.
. Lock stile:
• With door open, grasp lock stile of door and attempt
to move horizontally and vertically.
• There should be no looseness in the door pivots or in
connections between door and operator.
. Breakout stop:
• Center pivoted in swinging doors may be supplied
with an emergency breakout stop or switch that will
allow the door to open in the direction of emergency
egress.
• When the door is pushed into the breakout mode,
check that the door will not activate.
WARNING
If there are any problems, discontinue door
operation immediately and secure the door in
a safe manner.
Call your local dormakaba USA Inc. distributor
for repair.

Dormakaba ED100 Specifications

General

Type	Universal
Purpose	Interior door
Product color	Gray
Hand orientation	-
Maximum door width	- mm
Maximum door weight	- kg
Placement supported	Overhead concealed door closer
Suitable for door type	Single-leaf door
Power source type	DC

Weight and Dimensions

Width	1422 mm
