ED50/ED100/ED250 09-2021DL4616-011
dormakaba ED50/ED100/ED250 Owner's Manual
Overhead concealed header
Chapter 1
. ED/ED/ED OHC header Installation.
NOTICE
Exterior door use.
To insure proper suitability for exterior door
use, the following topics must be addressed in
the context of the door application setting.
• Site-specific use factors such as high wind
conditions and/or building pressure.
• Door width, height, weight, and usage
patterns.
• Observable prevailing conditions at the
opening under which the operator is
expected to perform. In some instances, this
may require increased force settings to
counteract these conditions.
• Door mounted presence sensors.
When attempting to overcome these forces,
it is strongly suggested that door mounted
presence sensors be employed to enhance
pedestrian safety through the opening.
General information
Fig.1.1 Single door OHC header with overhead arm
. Manual storage.
This document must be kept in a secure place, and
accessible for reference as required.
If the door system should be transferred to another
facility, insure that this document is transferred as well.
. dormakaba.us website.
Manuals are available for review, download, and printing
on dormakaba.us website.
. Dimensions
Unless otherwise specified, all dimensions are given in
inches (“).
. Symbols used in this manual.
WARNING
This symbol warns of hazards which could result
in personal injury or threat to health.
NOTICE
Draws attention to important information
presented in this document.
. Owner's manual.
This Owner's manual applies to dormakaba
ED/ED/ED swing door operators packaged
in an overhead concealed header (OHC).
Fig. 1.2 ED50 low energy OHC operator
Fig.1.3 ED100/ED250 OHC operator
