Dormakaba ED100 Owner's Manual

15
ED50/ED100/ED250 09-2021DL4616-011
dormakaba ED50/ED100/ED250 Owner's Manual
Overhead concealed header
Chapter 7
. Door signage, full energy power operated single swing doors
(ANSI/BHMA .)
Fig. 7.3.1 One decal, one way traffic
Approach side Swing side
Fig. 7.3.3 One decal, two way traffic
. Door signage, low energy power operated single swing doors
(ANSI /BHMA .): initiation of door operation
Fig. 7.4.1 Knowing act device
Fig. 7.3.2 One way traffic
Approach side Swing side
Fig. 7.3.4 Two way traffic
Approach side
Swing side
Approach side
Swing side
Fig. 7.4.2 Push/Pull
Push To Operate
Pull To Operate
50” ± 12”
AUTOMATIC
DOOR
DD0739-010
AUTOMATIC
DOOR
DO NOT
ENTER
50” ± 12”
AUTOMATIC
DOOR
CAUTION
DOOR
AUTOMATIC
DD0756-010
dormakaba
50” ± 12”
CAUTION
DOOR
AUTOMATIC
DD0586-010
DD0758-010
ACTIVATE SWITCH
TO OPERATE
DD0758-010
DD0758-010
ACTIVATE SWITCH
TO OPERATE
DD0758-010
CAUTION
DOOR
AUTOMATIC
DD0586-010
DD0758-010
ACTIVATE SWITCH
TO OPERATE
DD0758-010
DD0758-010
ACTIVATE SWITCH
TO OPERATE
DD0758-010
50” ± 12”
CAUTION
DOOR
AUTOMATIC
DD0586-010
DD0762-020
PULL
TO OPERATE
DD0762-020
PULL
TO OPERATE
CAUTION
DOOR
AUTOMATIC
DD0586-010
DD0762-010
PUSH
TO OPERATE
DD0762-010
PUSH
TO OPERATE

Dormakaba ED100 Specifications

General

Type	Universal
Purpose	Interior door
Product color	Gray
Hand orientation	-
Maximum door width	- mm
Maximum door weight	- kg
Placement supported	Overhead concealed door closer
Suitable for door type	Single-leaf door
Power source type	DC

Weight and Dimensions

Width	1422 mm
