dormakaba Quick Start Guide
22
8.2 Closing the escape route
Personnel
• Operator
Requirements
• At least two people must be present.
Fig. 17 Folding the door wing back
1.
Have one person hold the folded wing on the opposite
side ( Fig. 17 /1).
2.
Pull the folded wing ( Fig. 17 /2) until the wing snaps in.
3. Fold other wings back to their starting position as
necessary by following steps 1-2.
Fig. 18 Door wings in the starting position
» The escape route is reset ( Fig. 18 /1).
The procedure described below applies for re-
volving doors with three and four door wings.
WARNING!
Risk of injury if door is held onto inappropri-
ately!
WARNING!
Risk of crushed limbs at the closing edges!
