06-2023 dormakaba Canada Inc. RAC5 MFC Installation Guide – PK3738 | 9
3.2 Exploded View
Figure 4 Exploded View
4 System Installation Overview
Before starting installation:
• Ensure all components ordered and materials/tools required are available
• Ensure all cabling is available for the peripherals/components being installed
All installations and wiring of RAC5 MFC enclosure & peripherals must comply with all
applicable local building codes and regulations and National Electric Code, ANSI/NFPA 70.
Do not connect power to the enclosure until the end of the installation.
