Dormakaba RAC5 MFC - Power Adapter; Installation Hardware Bag; Tools Required (Not Supplied)

06-2023 dormakaba Canada Inc. RAC5 MFC Installation Guide – PK3738 | 8
3.1.5 Power Adapter
NOTE: Dependent
(J) 1x International 24 VDC output Adapter with integrated 6-foot (1.8m) power cable and interchangeable
AC outlet prongs. Input power requirements of 100-240 VAC, 50 60 Hz, 1.0A
Or
(K) 1x North America 24 VAC output power adapter with 2 separate 10-foot (3m) power cable assembly (2x
18 AWG cables terminated on one end with fork terminals). Input power requirements of 110-120 VAC, 60
Hz.
3.1.6 Installation Hardware Bag
(L) 4x Philips wood screw, #8 x 1-
(M) 4x Nylon anchor, #6-10
(N) 4x Concrete anchor, #7-9
(O) 2x Strain relief connector with locking nut
(P) Ring terminal connector
(Q) 5x Steel flat washer, #8
(R) 2x Crimp fork terminals, 18-22 AWG
3.1.7 Tools Required (not supplied)
Additional tools may be required dependent on the peripherals being installed. The list below covers the
installation of the RAC5 MFC enclosure only.
• Safety glasses
• Ink marker
• Electric drill
•
•
•
•
• Philips screwdriver - #2
• Slotted screwdriver
• Adjustable wrenches
• Crimp tool 18-22 AWG
• Pliers
• Wire cutter/stripper
• Hammer or rubber mallet
• Awl or center punch
