8 Annex D: RAC5 MFC Components
Figure 10 RAC5 MFC Components
SURFACE MOUNT
FLUSH MOUNT
ROUND READER
RING TERMINAL
SHIELDED CAT 5 OR RS422
RS485 COMPATIBLE 22 GAUGE
TWISTED PAIR STRANDED,
SHIELDED CABLE. CABLE TO BE
SUPPLIED BY PROPERTY.
IMPEDANCE OF CABLE TO BE 100
OHMS. MAXIMUM LENGTH OF
CABLE IS 1000 FT.
RAC5 MULTI-FLOOR CONTROLLER (MFC)
T53-XXXXX
NORTH AMERICAN POWER ADAPTER 062/511929R
INTERNATIONAL POWER ADAPTER 126-515160-1
