Saflok RT/RT Plus Installation Guide PK3720_T 04-19 5
2 Checklist continued
Parts inside hardware bag:
(C1) 1x Cylinder plug (for K model only)
(E1) 1x Cylinder cap (for K model only)
(F) 1x Thumbturn (hex) spindle
(G) 1x Square spindle
(H) 1x Torx-head screw
(I) 3x Mounting screws (10-24, ⁄ Hex Head) or (12-24, ⁄" Hex Head for recent models only)
(J) 2x Machined screws (12-24X ⁄" Philips) & 2 wood screws (#12 X 1" Philips)
(K) 1x Strike kit (screws, strike and ASM or Cylindrical dustbox)
(L) 1x Extension spring
(M) 1x Parts required to control thumbturn motion for (ASM and ESM Storeroom, ASM Office See appendix A3 & A4)
(S) 3x Spacers
(Y) 4x Pairs of Flat Head Screws 10-24 (for cylindrical only, see appendix B door thickness table)
(Z) 3x Spacers (for cylindrical only, see appendix B door thickness table)
Tools Required:
• Safety glasses
• ⁄" (13mm) chisel
• ⁄" (3mm) drill bit
• ⁄" (6.5mm) drill bit (ESM only)
• ⁄" (13mm) drill bit
• ⁄" (22mm) drill bit or hole saw
• 1" (25.4mm) drill bit or hole saw
• Drill
• Awl or center punch
• 2 ⁄" (54mm) hole saw (Cylindrical Only)
• Hammer Rubber mallet
• Small flat screwdriver
• Torx screwdriver (T-15) (760 Series)
• Phillips screwdriver (#2)
• Fine steel file
• Mortising machine
• Router
• Mortise face plate router template
• Adjustable square
• Tape measure
• Pencil
• Tape
• Installation Jig (Recommended)
• Lock Template
• Cleaning supplies (drop cloth, vacuum)
• ⁄" Allen Key
• ⁄" Allen Key
CAUTION
WARNING
IMPORTANT
For doors more than 2 ⁄" thick up to 3 ⁄", order the appropriate hardware bag to receive the correct length of spindles and
mounting screws. Part# 062-512868-XXX; (XXX = choice of finish).
For outdoor installations, order gasket 033-512017-1. Gasket comes standard with cylindrical locks and ultra finish locks.
