DP Megacontrol Series User Manual

40
3-4-1-4-8-2 Threshold 1 OFF 0
50
199.9
e s Water level at which the relays output becomes
""low""
3-4-1-4-8-3 Threshold 2 ON 0
40
199.9
e s Water level at which the relays output becomes
""high""
3-4-1-4-8-4 Threshold 2 OFF 0
40
199.9
e s Water level at which the relays output becomes
""low""
3-4-1-4-9 Supply valve ON/OFF e n The supply valve open/closed with which the
receiver tank is filled
3-4-1-4-9-1 Level 1 open 0
70
99.9
e s Level in the receiver tank at which the supply
valve is opened
3-4-1-4-9-2 Level 1 closed 0
90
99.9
e s Level in the receiver tank at which the supply
valve is closed
3-4-1-4-9-3 Level 1A open 0
40
99.9
e s Alternative level (Clock alternated) in the receiver
tank at which the supply valve is opened
3-4-1-4-9-4 Level 1A closed 0
60
99.9
e s Alternative level (Clock alternated) in the receiver
tank at which the supply valve is closed
3-4-1-4-10 Supply valve prop. e n The supply valve proportional opened with which
the receiver tank is filled
3-4-1-4-10-1 Level setpoint 1 0
80
99.9
e s Maximum level in the receiver tank at which the
proportional valve is fully closed
3-4-1-4-10-2 Level setpoint 1A 0
40
99.9
e s Alternative level (Clock alternated) in the receiver
tank at which the proportional valve is fully closed
3-4-1-4-10-3 Hysteresis 0
15
99.9
e s Differential level in the receiver tank at which the
proportional valve is fully opened
3-4-1-4-10-4 Sample time 0
10
99
e s Time between the level measurements controlling
the proportional valve position
3-4-1-4-10-5 Analog output 4-20 mA
0-20 mA
e s Analog output configuration, 4-20mA / 0-20mA
3-4-1-4-10-6 Open band 0
2
15
e s Band below the setpoints 1 and 1A, at which the
prop. control of the valve is suppressed.
3-4-1-4-11 Water supply control e s
3-4-1-4-11-1 Level RW-pump Off 70
90
99.9
e s Level in the tank at which the rainwater pump is
switched off.
3-4-1-4-11-2 Level RW-Pumpe On 40
70
90
e s Level in the tank at which the rainwater pump is
switched on and the potable water inlet valve is
closed.
3-4-1-4-11-3 Level DW-valve open 0
40
70
e s Level in the tank at which the potable water inlet
valve is opened.
3-4-1-4-11-4 Overflow protection OFF
ON
e s Overflow protection to stop any water inlet if digital
input "Leakage" is activated.
Parameter Display text Value
1
description Min./Max. Read Write Help text
