39
3-3-4 WSD OFF
1 tank
2 tanks
3 tanks
1 tank + temp
2 tanks + temp
3 tanks + temp
Temperature
e s Setting of the applicable configuration of the WSD:
(membrane tank refreshments and ambient temp.)
3-3-5 Leakage detection ON
OFF
e s Leakage detection
3-3-6 MPO Functionality OFF
ON
s s Synchron pump operation
3-3-7 PumpMode int/ext Internal
External
e s Pump mode is either Internaly (Via HMI or Serv-
ice) or externaly (via digital input) changed.
3-4 System settings e n System parameter settings
3-4-1 Inlet e n Parameter setting for the inlet connection (suction
side of the system)
3-4-1-1 Sensor press. 4 mA -100
0
1000
e s Measured value at 4mA
3-4-1-2 Sensor press. 20 mA 0
1000
9999
e s Measured value at 20mA
3-4-1-3 Damp. Time Inlet 100
200
2000
f f Damping time for smoothing the measured value,
to compensate peaks in the measured values
3-4-1-4 Level config e s Parameter setting for the level control in the
receiver tank (storage tank at suction side)
3-4-1-4-1 0% level 0
99
e s Lowest possible level in the receiver tank at which
no air is sucked in. In relation to the bottom
3-4-1-4-2 100% level 0
200
999
e s Highest possible level in the receiver tank before
overflow is triggered. In relation to the bottom.
3-4-1-4-3 Sensor level -100
0
999
e s The position where the level sensor is located in
the receiver tank. In relation to the bottom.
3-4-1-4-4 Low level shut down 0
10
99.9
e s Low water level to protect the pumps for dry run-
ning. (system shut down)
3-4-1-4-5 Low level reset 0
15
99.9
e s Reset level to reset the system after low level shut
down
3-4-1-4-6 Critical water level 0
30
99.9
e s Critical level at which the tank threatens to
become empty. (back-up storage left)
3-4-1-4-7 High water level 0
105
199.9
e s High water level at which the tank threatens to
become over-full
3-4-1-4-8 Threshold e s Menu for having one or two extra contacts
switched at a level set as required
3-4-1-4-8-1 Threshold 1 ON 0
50
199.9
e s Water level at which the relays output becomes
""high""
Parameter
Display
text
Value
1
description
Min./Max.
Read
Write
Help text
