42
3-4-2-1 Sensor press. 4 mA -100
0
1000
e s Measured value at 4mA
3-4-2-2 Sensor press. 20 mA 0
1000
9999
e s Measured value at 20mA
3-4-2-3 Pumps ON sensor fail 0
3
e s Number of pumps that is started in case of a fail-
ure of the pressure sensor on the discharge side.
3-4-2-4.1 Max power 0
600
n e dummy to map slection ENUM to UINT16
3-4-2-4.2 Max power 100%
200%
300%
400%
500%
600%
e s Limitation of the maximum power / maximum sys-
tem load (1 pump is 100%)
3-4-2-5.1 Max power ext. oper. 0
600
n e dummy item to map selection ENUM to UINT16
3-4-2-5.2 Max power ext. oper. 100%
200%
300%
400%
500%
600%
e s Limitation of the maximum power / maximum sys-
tem load, when external power supply operation is
active
3-4-2-6 Damp. Time P. Sensor 100
200
2000
f f Damping time for smoothing the measured value,
to compensate peaks in the measured values
3-4-3 Variable freq. drive e n Configuration of variable frequency drive
3-4-3-1 Communication None
Analog 4-20mA
Analog 0-20mA
PumpDrive 1
PumpDrive 2
Danfoss VLT 2800
Danfoss MicroDrive
Danfoss AquaDrive
e s Configuration of the communication protocol of
the frequency converter
3-4-3-2 Proportional const. 0
3
100
e s Proportional amplification factor the system pres-
sure is controlled with
3-4-3-3 Integral time 0
0.9
60
e s Speed with which the deviation of the required
system pressure is adjusted
3-4-3-4 Differential time 0
99.99
e s The level of damping with which the deviation of
the required system pressure is controlled
3-4-3-5 No flow detection e s Accuracy of which the minimum water demand
""no-flow"" is detected (System switch-off proce-
dure)
3-4-3-5-1 No flow bandwith 0
6
50
s s Bandwith of the no flow detection
3-4-3-5-2 No flow time 0
16
600
s s Time of the no flow detection in s
3-4-3-5-3 No flow step 1
3
50
s s Step height of the no flow detection in %
Parameter
Display
text
Value
1
description
Min./Max.
Read
Write
Help text
