DP Megacontrol Series User Manual

43
3-4-3-5-4 No flow max. power 0
100
s s No flow detection is active below this Pump load in
%
3-4-3-9 VFD Ramp-Up 0.1
3
999
e s Setting of the ramp-up of the VFD
3-4-3-10 VFD Ramp-Down 0.1
3
999
e s Setting of the ramp-down of the VFD
3-4-3-11 VFD min. frequency 0
30
140
e s Minimum frequency of the VFD
3-4-3-12 VFD max. frequency 30
50
140
e s Maximum frequency of the VFD
3-4-3-13 P nominal of VFD 0
1500
100000
e s nominal power of the VFD
3-4-3-14 U nominal of VFD 0
400
500
e s nominal voltage of the VFD
3-4-3-15 F nominal of VFD 50
140
e s nominal frequency of the VFD
3-4-3-16 I nominal of VFD 0
4
450
e s nominal current of the VFD
3-4-3-17 RPM nominal of VFD 0
2880
10000
e s nominal speed of the VFD
3-4-3-18 BCC Failure DelayCnt 0
1
200
d d BCC Failure Delay Count
3-4-3-19 ARW delay factor 5
50
200
d d Setting for ARW control, sampletime factor tarw
>= 5 * ts
3-4-3-20 Motor Speed Unit RPM
Hz
e s Unit of motor speed
3-4-3-21 Digital I/P 33 func. No Function
Coasting stop inv.
e s Selection of digital input
3-4-3-22 Digital I/P 29 func. No Function
Jog Function
Jog Function
e s Selection of digital input
3-4-3-23 Jog frequency 30
50
e s Motor speed manual mode
3-4-3-24 Jog ramp time 0.04
5
3600
e s Ramp time
3-4-3-25 Costing select Digital Input
Bus
Digital And Bus
Digital Or Bus
e s Selection manual mode
3-4-3-26 Start select Digital Input
Bus
Digital And Bus
Digital Or Bus
e s Selection start signal
Parameter Display text Value
