DP Megacontrol Series User Manual

50
3-8-1-10 Function RDP OFF
ON
s s Functionality of digital input RDP
3-8-1-11 Function TFR OFF
ON
s s Functionality of digital input TFR
3-8-1-12 Function TVA OFF
ON
s s Functionality of digital input TVA
3-8-1-13 Functionality OFF OFF
ON
s s Evaluation of digital input OFF
3-8-1-14 Function FIRE OFF
ON
s s Functionality of digital input FIRE
3-8-2 Outputs s n Configurable outputs
3-8-2-1 Conf. P4 (DO) None
Threshold relay 1
Threshold relay 2
Input valve
By-pass valve
RDP Alarm O/P
Low water level
Operational avail.
s s Configuration of digital output P4
3-8-2-2 Conf. P5 (DO) None
Threshold relay 1
Threshold relay 2
Input valve
By-pass valve
RDP Alarm O/P
Low water level
Operational avail.
s s Configuration of digital output P5
3-8-2-3 Conf. P6 (DO) None
Threshold relay 1
Threshold relay 2
Input valve
By-pass valve
RDP Alarm O/P
Low water level
Operational avail.
s s Configuration of digital output P6
3-8-2-4 Conf. FR4 (DO) None
Threshold relay 1
Threshold relay 2
Input valve
By-pass valve
RDP Alarm O/P,Low
water level
Operational avail.
s s Configuration of digital output FR4
3-8-2-5 Conf. FR5 (DO) None
Threshold relay 1
Threshold relay 2
Input valve
By-pass valve
RDP Alarm O/P
Low water level
Operational avail.
s s Configuration of digital output FR5
Parameter Display text Value
1
description Min./Max. Read Write Help text
