51
3-8-2-6 Conf. FR6 (DO) None
Threshold relay 1
Threshold relay 2
Input valve
By-pass valve
RDP Alarm O/P
Low water level
Operational avail.
s s Configuration of digital output FR6
3-8-2-7 Opert./Fail. Relay OFF
ON
ss
3-8-2-8 Conf. FR (AO) None
System pressure
System load
Level height
Inlet pressure
s s Configuration of analog output FR (AO)
3-8-2-9 Output Range (FR) 4-20 mA
0-20 mA
s s Configuration of output current of FR
3-8-2-10 Conf. VALVE (AO) None
System pressure
System load
Level height
Inlet pressure
s s Configuration of analog output VALVE (AO)
3-8-2-11 Output Range (VALVE) 4-20 mA
0-20 mA
s s Configuration of output current of VALVE
3-9 Messages s n Messages
3-9-1 Message Settings s s List of all alerts
3-9-1.1.1 #0-0 failure id Failure PT. Dis. ss
Sys. press.to low
Sys press.to high
No water
Maintenance req.
More pumps fail
No refresh tank #
Aver temp to high
Curr temp to high
Temp. Fail. Pump #
Failure valve
Inlet sensor fail
High water level
Crit. water level
Low water level
Comm. Error FC #
incor. check sum F#
Temp. sensor fail
24V out of range
5V out of range
3V out of range
External off
Fire alarm
Parameter
Display
text
Value
1
description
Min./Max.
Read
Write
Help text
