DR 18 HP User Manual

14 DR
®
18 and 19 HP ROAD-TOWABLE CHIPPER
Unpacking the DR ROAD-TOWABLE CHIPPER
NOTE: Unpacking the DR ROAD-TOWABLE CHIPPER is a two-person job. We recommend you have an extra
set of hands available before you begin as the 18 HP model weighs 385 lbs. and the 19 HP model
weighs 470 lbs.
Tools and Supplies Needed:
• Gloves
• Metal Shears (Side Cutters)
• Eye Protection
• Pry Bar
• Hammer
Parts supplied on Skid:
• (1) DR ROAD-TOWABLE CHIPPER
• (1) Discharge Chute (19 HP Top Discharge model)
• (2) Hitch Arms
• (1) Hitch Assembly
• Parts Box containing:
- (1) Chipper Hopper
- (1) Swivel Top (19 HP Top Discharge model)
- (1) Deflector (19 HP Top Discharge model)
- (1) Stand Assembly
- (1) Safety Glasses
- (1)
Safety & Operation Instructions Manual
- (1) Engine Owner’s Manual
- (1) Wire Harness
- (10) Cable Ties
- (1) Knife Gap Gauge
- (1) Plastic Bag containing the following miscellaneous mounting hardware:
19 HP, Top Discharge Model 18 HP, Bottom Discharge Model
(7) 5/16" - 18 x 3/4" Carriage Bolt (4) 5/16" - 18 x 3/4" Carriage Bolt
(8) 5/16" - 18, Lock Nut, Nylon (4) 5/16" - 18, Lock Nut, Nylon
(4) 5/16" USS Flat Washer (4) 5/16" USS Flat Washer
(2) 1/2"- 13 x 3" Bolt (2) 1/2"- 13 x 3" Bolt
(4) 1/2"- 13 x 1-1/4" Bolt (4) 1/2"- 13 x 1-1/4" Bolt
(2) 1/2"- 13 Lock Nut (2) 1/2"- 13 Lock Nut
(1) 3/16" Hairspring Cotter Pin (1) 3/16" Hairspring Cotter Pin
(2) Hitch Arm Mount Plates (2) Hitch Arm Mount Plates
(2) Engine Key (2) Engine Key
(2) 5/16" - 18 x 3/4" Bolt
(3) 3/8" USS Flat Washer
(1) Locking Knob
