54 DR
®
18 and 19 HP ROAD-TOWABLE CHIPPER
Parts List - 19 HP Control Panel Assembly
NOTE: Part numbers listed are available through Country Home Products, Inc.
Ref# Part# Description
01 913-0446 Frame
02 913-0432 Support, Tank
03 202131 Screw, 10 - 24 x 3/4"
04 913-0433 Cover, End
05 143130 Nut, Nylon Lock, 5/16" - 18
06 202121 Nut, Nylon Lock, 10 - 24
07 112111 Cable, Throttle
08 030-0467 Cable, Choke
09 913-0453 Hose, Fuel
10 166790 Bolt, 5/16" - 18 x 3/4" HHCS
11 150291 Fuel Tank Assembly
12 150531 Strap, Tank
13 030-0469 Clamp, Hose
14 030-0473 Cable, Starter
15 143400 Nut, Nylon Lock, 1/4" - 20
16 030-0470 Solenoid
17 090-0012 Bolt, 1/4" - 20 x 3/4" HHCS
18 913-0431 Base, Tank
19 030-0471 Switch, Ignition
20 155120 Screw, 10 - 32 x 3/8"
Not Illustrated
030-0472 Wire Harness
