56 DR
®
18 and 19 HP ROAD-TOWABLE CHIPPER
Parts List - Basic Machine Assembly - 18 and 19 HP
NOTE: Part numbers listed are available through Country Home Products, Inc.
Ref# Part# Description
01 18613 Nut, Lock, 5/16" - 18
02 18605 Bearing, Side
03 14515 Washer, Flat, 5/16" USS
04 090-0049 Nut, Lock, 3/8"-16
05 18301 Retaining Ring
06 20390 Shim
07 15512 Screw, Self -Tapping, 10-32 x 3/8"
08 16798 Cover, Access
09 16149 Plate, Drive Side
10 14313 Nut, Lock, Nylon, 5/16" - 18
11 16762 Knife (Kit)
12 15905 Screw, 5/16" - 18 x 1-1/2", FHSHCS
13 20627 Flywheel/Chipper Disk - Complete (18HP)
16656 Flywheel/Chipper Disk - Complete (19HP)
14 16665 Scroll, 18 HP (Bottom Discharge)
16804 Scroll, 19 HP (Top Discharge)
15 16814 Plate, Chipper Side
16 14340 Nut, Lock, Nylon, 1/4" - 20
17 14339 Washer, Flat, 1/4" SAE
18 15539 Bolt, 5/16" - 18 x 4" HHCS
19 20212 Nut, Lock, Nylon, 10 - 24
20 20213 Screw, 10-24 x 3/4", PHMS
21 20015 Shield, Blow Back
22 14529 Bolt, Carriage, 5/16" - 18 x 3/4"
23 19905 Chipper Hopper (Kit)
24 18265 Wear Plate,
25 19566 Bolt, Carriage, 1/4" - 20 x 1"
26 15449 Bolt, 3/8" - 16 x 1-1/4" HHCS
27 18313 Tube, Scroll
28
16706 Shaft, Flywheel
29 14074 Taper Lock Bushing, Flywheel
Not Illustrated
200140 Strip, Mounting, Blow Back Shield
