CALL TOLL FREE 1-800-DR-OWNER 37
Figure 16
Drive Pulley
Hub Bolt
Hub Retaining
Bolt (3 places)
Bushing Saw Slot
Threaded
Holes (3)
Drive
Pulley
Bushing
Rotor
Shaft
